Detail Information

Coating Color:	Customizable	Corrosion Resistance:	Excellent
Specification:	Qeq	Type:	Coil
Alloy Or No:	Alloy	Standard:	GB/T3880 ASTM B209 EN485
Tolerance:	±2%	Color:	Natural Color Or Customized
Surface Treatment:	Mill Finish, Anodized, Powder Coated, Etc.	Item:	Aluminum Diamond Plate Thickness
Hs Code:	76061259	Productivity:	2000 Metric Ton /month
Alloy Or Not:	Non-Alloy	Surface:	Polished/Smooth
Width:	600mm - 2000mm
Highlight:	Anti Scratch Aluminum Steel Coil , Aluminum Steel Coil 0.6mm , Aluminum Steel Coil 2.0mm Thick

Product Description

Anti-Scratch Aluminum Steel Coil 0.6-2.0mm Thick Automotive Body Panels ISO Certified

Anti-Scratch Aluminum Steel Coil is a cutting-edge material engineered for automotive body panels requiring exceptional durability, aesthetics, and lightweight performance. Compliant with ISO 9001 and IATF 16949 automotive standards, this coil combines a 55% aluminum-zinc alloy coating with an advanced anti-scratch topcoat, available in 0.6–2.0mm thicknesses and custom widths. Designed to resist abrasion, stone chips, and UV degradation, it ensures long-lasting surface quality for vehicles while reducing manufacturing costs and environmental impact.

Key Selling Points:

Anti-Scratch Protection: Nano-ceramic topcoat (3H pencil hardness) resists scratches and swirl marks.
Lightweight Strength: Tensile strength up to 500 MPa, 20% lighter than traditional steel.
Corrosion Resistance: Aluminum-zinc coating withstands salt spray (1,500+ hours, ASTM B117).
Aesthetic Versatility: Pre-painted options in automotive-grade colors (RAL, Pantone) or glossy/matte finishes.
Eco-Certified: REACH and RoHS compliant, supporting sustainable vehicle manufacturing.

2. Detailed Specifications

Parameter	Details
Material	Aluminum-Zinc Alloy Coated Steel (55% Al, 43.4% Zn, 1.6% Si)
Base Steel Grade	HX340LAD (EN 10346) / ASTM A653 SS Grade 40
Coating Weight	120–180 g/m² (AZ120, AZ150, AZ180)
Thickness	0.6mm – 2.0mm (±0.03mm tolerance)
Coil Width	800mm – 1,800mm (Custom slitting available)
Surface Finish	Anti-scratch coated, pre-painted, or mill finish
Certifications	ISO 9001, IATF 16949, EN 10346, ASTM A653, JIS G3321
Primary Applications	Car doors, hoods, fenders, EV battery enclosures, truck trailers

3. Advantages of Importing Our Automotive-Grade Coils

Why Partner With Us?

Cost Leadership: 20-25% lower pricing than EU/Japanese suppliers with full IATF 16949 compliance.
Fast Turnaround: 8–12 days lead time for custom orders (MOQ: 15 tons), including coating and slitting.
Quality Guarantee: Third-party tested for hardness (ASTM D3363) and adhesion (ISO 2409 cross-cut test).
Custom Solutions: Embossed textures, laser-cut patterns, or OEM-branded finishes.
Global Logistics: Scratch-resistant VCI film packaging and Incoterms support (FOB, CIF).
Technical Expertise: Free prototyping and material selection guides for automotive OEMs.

4. Automotive & Transportation Applications

Industry	Use Cases
Passenger Vehicles	Car body panels, roof rails, bumper reinforcements, wheel arches.
Electric Vehicles	Battery tray covers, charging port flaps, lightweight chassis components.
Commercial Vehicles	Truck cabin exteriors, trailer siding, bus body frames.
Motorcycles	Fuel tank covers, fairings, anti-abrasion guards.
Public Transport	Train exterior cladding, metro door panels, tram body shells.
Aftermarket Parts	Custom car wraps, replacement panels, automotive accessories.

FAQ

1. Who are we?

We are based in Jiangsu, China, start from 2008,sell to Mid East(25.00%),South America(15.00%),Southeast Asia(15.00%),North America(10.00%),Africa(10.00%),Domestic Market(10.00%),Eastern Europe(5.00%),Oceania(5.00%),South Asia(5.00%). There is a total of about 31-50 people in our office.

2. How can we guarantee the quality?

Always a pre-production sample before mass production;Always final Inspection before shipment;

3. What can you buy from us?

Stainless Steel Plate/Stainless Steel Pipe/Stainless Steel Profile, Steel Plate/Steel Pipe,Aluminum Steel Coil

Tag:

Place of Origin:	CHINA AnHui
Brand Name:	Chinalco，CHINA STEEL UNION
Certification:	ISO9001,SGS, ASTM, ASME
Model Number:	Thickness 0.1mm-20mm, can be customized

Minimum Order Quantity:	1000Kilogram
Price:	1399-3066USD
Packaging Details:	Steel strip + kraft paper + fumigated wooden box export exquisite packaging
Delivery Time:	2-3Days
Payment Terms:	T/T, L/C, Western Union, MoneyGram
Supply Ability:	800000KG/15Days

Anti Scratch Aluminum Steel Coil 0.6mm-2.0mm Thick For Automotive Body Panels
