PPGI Steel Coil EN10169 Compliant | Pre-Painted Galvanized Steel For Automotive Parts
EN10169-compliant PPGI Steel Coils are engineered for automotive manufacturers seeking high-performance, corrosion-resistant materials that meet stringent European standards. Featuring a Z140–Z275 galvanized base and 15–30µm polyester/silicon-modified polyester (SMP) coatings, these coils deliver exceptional durability, formability, and aesthetic consistency for automotive exteriors, interiors, and EV components. Certified to IATF 16949, ISO 9227, and EN 10169, they ensure compliance with global automotive quality and safety regulations.
Key Advantages:
- Automotive-Grade Precision: Tight thickness tolerances (±0.02mm) for stamping, deep drawing, and welding.
- Corrosion Resistance: Passes 1,000-hour salt spray test (ISO 9227) for underbody and exposed parts.
- Lightweight Strength: High-strength steel (TS: 340–600 MPa) with 25% weight reduction vs. traditional materials.
- Aesthetic Durability: ≤1.0ΔE color shift after 5 years of UV exposure (SAE J2527 testing).
- Eco-Friendly: REACH/RoHS-compliant coatings + 30% recycled steel content.
- Custom Solutions: Pre-coated coils in OEM-specific colors (RAL, Pantone) + embossed textures.
2. Technical Specifications
| Parameter |
Details |
| Base Material |
Ultra-Low Carbon Steel (C: ≤0.04%, Mn: 0.15–0.50%, Si: ≤0.03%, P/S: ≤0.015%) |
| Coating Layers |
Hot-Dip Galvanized (Z140–Z275) + Chromium-Free Primer + Polyester/SMP (15–30µm) |
| Grades |
EN 10169 (DX54D+Z), ASTM A755 (SS330, SS550), JIS G3312 (SGACEN) |
| Thickness Range |
0.6mm–2.5mm (±0.02mm for ≤1.0mm, ±0.04mm for >1.0mm) |
| Coil Dimensions |
Width: 800–1,500mm (±0.5mm), ID: 508/610mm, Max OD: 1,800mm |
| Mechanical Properties |
Tensile Strength: 340–600 MPa, Yield Strength: 210–450 MPa, Elongation: 18–30% |
| Surface Properties |
Gloss: 40–80 GU, roughness Ra ≤0.4µm, adhesion (ISO 2409): Class 0 |
| Certifications |
EN 10169, IATF 16949, ISO 9227, SAE J2340, TÜV Nord, IMDS Compliance |
| Primary Applications |
Car door panels, EV battery housings, truck cabins, and chassis components |
3. Why Import Our EN10169 PPGI Coils?
Competitive Edge:
- Cost Savings: 20–30% lower than EU suppliers with identical IATF 16949 certification.
- Just-in-Time Delivery: 12-day production + air freight options for urgent orders (e.g., 0.8mm EV battery trays).
- Zero Defects: AI-driven surface inspection (≥99.98% accuracy) + 100% hardness/coating thickness checks.
- Customization: Laser-cut blanks, pre-treated weld zones, and EMI shielding coatings for EVs.
- Supply Chain Transparency: Blockchain-tracked raw materials (Conflict-Free Sourcing Initiative compliance).
- Technical Support: Free GD&T reports, NVH simulation data, and OEM-specific packaging.
- Warranty: 10-year corrosion warranty + 3-year color retention guarantee for automotive exteriors.
4. Automotive & Transportation Applications
| Application |
Use Cases |
| Passenger Vehicles |
Roof panels, fenders, trunk lids, and interior trim with soft-touch finishes. |
| Electric Vehicles (EVs) |
Battery enclosure panels, charging port covers, and lightweight structural reinforcements. |
| Commercial Trucks |
Trailer siding, cab roofs, and load bed liners with anti-scratch coatings. |
| Public Transport |
Bus body panels, subway interior cladding, and railway seat backs. |
| Two-Wheelers |
Motorcycle fuel tanks, e-bike frames, and scooter footrests. |
| Specialty Vehicles |
Ambulance exteriors, fire truck compartments, and armored vehicle undercarriages. |
| Aftermarket Parts |
Custom hood wraps, alloy wheel protection films, and DIY repair kits. |
