Detail Information

Weight:	5-8 Tons/Plate	Origin:	China
Density:	7.93 G/cm³	Package:	Standard Seaworthy Package
Tickness:	0.5-3.0 Mm	Product:	Stainless Steel Plate
Feature:	Thin	Specification:	According To Customer Requirements
Inspection:	Mill Test Cert Or Third Party Inspection	Invoicing:	By Actual Weight
Processing Service:	Bending, Decoiling, Cutting	Standard Size:	10002000mm 12192438mm 1500*6000mm
Surfacefinish:	No.1, No.4, BA, Mirror	Thickness Tolerance:	±0.01mm
Highlight:	Lightweight Aluminium Alloy Ingot , Aluminium Alloy Ingot Corrosion Resistant , Aluminium Alloy Ingot 99.9% Purity

Product Description

AISI 430 Stainless Steel Plate Product Description

The AISI 430 stainless steel plate stands as a premier ferritic stainless steel solution, expertly engineered to deliver exceptional value where superior corrosion resistance paired with excellent formability is paramount. This AISI 430 plate offers a cost-effective alternative to nickel-based austenitic grades, providing outstanding performance in a wide array of moderately corrosive environments, making it a versatile and reliable choice for industrial and decorative applications alike.

Product Overview & Key Specifications

The AISI 430 stainless steel is a straight chromium ferritic grade known for its good corrosion resistance, engineering properties, and thermal conductivity. The AISI 430 plate is particularly valued for its resistance to nitric acid, organic acids, and sulfur compounds. Below are its core specifications in a concise table format.

Item	Specification / Description
Common Grade	AISI 430, UNS S43000, 1.4016
Key Composition	Chromium (Cr): 16.0-18.0%, Carbon (C): ≤0.12%
Density	7.7 g/cm³
Tensile Strength	≥ 450 MPa
Yield Strength	≥ 205 MPa
Key Feature	Good Corrosion Resistance, Excellent Formability, Cost-Effective

Characteristics & Selling Points

The primary advantage of the AISI 430 stainless steel plate lies in its optimal balance of performance and economy. It exhibits good resistance to atmospheric corrosion, many organic chemicals, and nitric acid. The AISI 430 plate possesses excellent ductility and can be readily formed, bent, and drawn. Furthermore, it demonstrates favorable thermal conductivity and low thermal expansion compared to austenitic grades. Its smooth surface finish is ideal for applications requiring an attractive appearance.

Technology & Manufacturing Process

Our AISI 430 plates are manufactured using state-of-the-art continuous casting and controlled hot-rolling technologies, ensuring a uniform microstructure and consistent mechanical properties throughout the plate. Precise annealing and pickling processes are employed to achieve the desired metallurgical structure, optimal corrosion resistance, and a clean, scale-free surface.

Typical Applications

The versatility of the AISI 430 stainless steel plate makes it suitable for numerous sectors. Common applications include:

•
Architectural & Decorative: Kitchen equipment, interior trim, automotive trim, washing machine drums.
•
Industrial Equipment: Heat exchangers, furnace parts, fuel burner parts, nitric acid tanks.
•
Consumer Durables: Appliance components, catering equipment, signage.

Advantages of Our AISI 430 Plates

•
Consistent Quality: Rigid quality control from melting to final inspection.
•
Precise Dimensions: Available in a wide range of thicknesses, widths, and lengths with tight tolerances.
•
Superior Surface Finish: Offered in standard 2B, BA, or No.4 finishes to meet specific needs.
•
Cost-Effectiveness: Provides excellent corrosion resistance at a lower cost than 304-grade stainless steel.

Service & Support

We provide comprehensive technical support, including material selection guidance and fabrication recommendations. Our products are available for global export, packaged securely to prevent damage during transit, and accompanied by full material certification (MTC).

FAQ

•
Q: How does AISI 430 compare to AISI 304?

A: The AISI 430 stainless steel plate offers good corrosion resistance but is generally not as corrosion-resistant as AISI 304, especially in chloride environments. However, the AISI 430 grade is more cost-effective and has better thermal properties.
•
Q: Is the AISI 430 plate magnetic?

A: Yes, as a ferritic stainless steel, the AISI 430 plate is magnetic.
•
Q: Can it be welded?

A: Yes, the AISI 430 plate can be welded using common methods, but it may be susceptible to reduced corrosion resistance and grain growth in the heat-affected zone. Proper techniques and post-weld annealing are recommended for critical applications.

Tag:

Place of Origin:	CHINA WUXI
Brand Name:	Jiangsu China Steel Union
Certification:	ISO9001,SGS, ASTM, ASME
Model Number:	SS304,SS316L,SS321,SS310S,SS2205,SS304H

Minimum Order Quantity:	1000KG
Price:	0.98-1.2USD/KG
Packaging Details:	Steel strip + kraft paper + fumigated wooden box export exquisite packaging
Delivery Time:	3-5Days
Payment Terms:	T/T, L/C, Western Union, MoneyGram
Supply Ability:	2 metric tons per month

AISI 430 Stainless Steel plate Highly corrosion resistant; can be processed into wire-drawn films.
