Eco-Friendly PPGI Steel Coils - UV-Resistant Coated Metal for Architectural Projects
Eco-Friendly PPGI Steel Coils are designed to meet the rising demand for sustainable, UV-resistant building materials in modern architecture. Featuring a 100% recyclable base and low-VOC polyester/polyurethane coatings, these coils deliver exceptional resistance to fading, cracking, and environmental degradation. Certified by LEED v4.1, Cradle to Cradle Silver, and GREENGUARD Gold, they are ideal for green buildings, solar-integrated façades, and urban infrastructure. Available in 0.3–2.0mm thicknesses and 600–1,300mm widths, they combine eco-conscious production with 25+ years of color retention under direct sunlight.
Key Advantages:
- UV-Resistant Technology: Nano-ceramic additives block 99% of UV rays (tested per ASTM G154).
- Sustainable Production: 70% recycled steel content + water-based coating process (Zero-VOC).
- Aesthetic Longevity: ≤1.5ΔE color shift after 5,000 hours of accelerated weathering (QUV testing).
- Lightweight & Durable: High-strength steel (TS: 340–600 MPa) with 20% lower carbon footprint.
- Acoustic & Thermal Insulation: Optional foam-backed or perforated designs for energy-efficient buildings.
- Global Certifications: Complies with EN 10169, ASTM D6577, and ISO 14064 sustainability standards.
- Quick Installation: Pre-fabricated panels with concealed fasteners for LEED-certified projects.
2. Technical Specifications
| Parameter |
Details |
| Base Material |
Recycled Low-Carbon Steel (C: ≤0.08%, Mn: 0.20–0.50%, Si: ≤0.04%, Al: 0.02–0.06%) |
| Coating Layers |
Galvanized (Z180–Z275) + Chromium-Free Primer + UV-Resistant Polyester/PU (20–30µm) |
| Grades |
EN 10169 (S250GD+Z), ASTM A755 (SS Grade 80), JIS G3312 (SGCC1) |
| Thickness Range |
0.3mm–2.0mm (±0.03mm for ≤1.0mm, ±0.05mm for >1.0mm) |
| Coil Dimensions |
Width: 600–1,300mm (±1mm), ID: 508/610mm, Max OD: 1,800mm |
| Mechanical Properties |
Tensile Strength: 340–600 MPa, Yield Strength: 250–450 MPa, Elongation: 15–22% |
| Surface Properties |
Gloss: 25–70 GU, roughness Ra ≤0.3µm, adhesion (ISO 2409): Class 0–1 |
| Certifications |
LEED v4.1, Cradle to Cradle Silver, GREENGUARD Gold, EDGE, ISO 14001, FSC Mix |
| Key Applications |
Solar façades, green rooftops, noise barriers, and eco-resort cladding |
3. Why Import Our Eco-Friendly PPGI Coils?
Competitive Benefits:
- Cost-Effective Green Solutions: 15–20% cheaper than EU-made eco-coils with identical certifications.
- Fast Global Delivery: Pre-stocked coils (5,000+ tons) + 10-day shipping to major hubs (Rotterdam, NYC, Tokyo).
- Quality Assurance: AI-powered optical sorting for zero coating defects + 2,000-hour salt spray resistance.
- Customization: Solar-reflective coatings (SRI ≥82), moss-resistant finishes, and textured woodgrain patterns.
- Carbon-Neutral Logistics: Partnered with DHL GoGreen and Maersk ECO Delivery for low-emission shipping.
- Technical Support: Free BIM models, LEED documentation, and lifecycle assessment (LCA) reports.
- Warranty: 15-year UV resistance warranty + 30% recycled content certification (SCS Global).
4. Sustainable Architectural Applications
| Project Type |
Use Cases |
| Commercial Green Buildings |
LEED-certified office façades, shopping mall canopies, and solar carports. |
| Public Infrastructure |
Noise barriers along highways, metro station roofs, and urban park pavilions. |
| Residential Eco-Homes |
Energy-efficient roofing, balcony screens, and rainwater harvesting panels. |
| Hospitality & Resorts |
Luxury eco-resort façades, poolside cabanas, and glamping pod exteriors. |
| Educational Institutions |
University campus rooftops, solar-integrated auditoriums, and green lab walls. |
| Healthcare Facilities |
Hospital courtyards, antimicrobial-coated walls, and healing garden enclosures. |
| Cultural Landmarks |
Museum atriums, art gallery exteriors, and heritage site restoration panels. |
FAQ
1. Who are we?
Our headquarters is located in Anhui, China. Since 2010, we have sold to the domestic market (30.00%), South Asia (10.00%), South America (10.00%), North America (10.00%), Southeast Asia (10.00%), and Africa (5.00%) , Northern Europe (5.00%), Central America (5.00%), Middle East (5.00%), Western Europe (3.00%), Oceania (3.00%), Southern Europe (2.00%), East Asia (1.00%), Eastern Europe (1.00%) . There are about 11-50 people in total in our factory.
2. How do we ensure quality?
There are always pre-production samples before mass production;
Always conduct final inspection before shipment;
3. What can you buy from us?
PPGI Steel Coil,PPGI Steel Sheet, stainless steel pipe, stainless steel coil, stainless steel strip, wear-resistant plate, galvanized steel plate
4. Why should you buy from us instead of other suppliers?
The company introduces advanced technology and equipment, and its products are exported to Western countries such as the United Kingdom and the United States. It has strong technical force and experienced technical and management personnel.
5. What services can we provide?
Accepted delivery terms: FOB, CFR, CIF, EXW;
Accepted payment currencies: USD;
Accepted payment methods: T/T, L/C, cash;
Languages spoken: English, Chinese
